Astell&Kern SP1000 AMP
Astell&Kern SP1000 AMP
Amplifier module for the SP1000 Hi-Res DAP
Made Only for the SP1000
An Amplifier module designed specifically for the SP1000 to drive full-sized, high-impedance headphones.
The SP1000 AMP offers High Gain output of 10 Vrms for Balanced output and 6.2 Vrms for Unbalanced output.
The modular design fits perfectly with your SP1000.
The SP1000 AMP adds more power and performance for your SP1000.
The SP1000 AMP offers 10 Vrms for Balanced output on the High-Gain setting.
The AMP has been designed to protect your hearing.
It adjusts the output every time the AMP is turned on and/or your headphone is disconnected from the AMP.
The AMP can be turned on and off easily from the quick settings menu. Gain can be adjusted in the full settings menu.
- When the SP1000 AMP is connected to the SP1000, Optical out, USB-DAC, USB-Audio, Line-Out and CD-Ripping functions will not be available.
Improved output performance
The SP1000 AMP offers higher power output and better efficiency*, using updated circuitry and audio volume control.
(* compared to the AK380 AMP module)
3,700 mAh Large-capacity Battery
The SP1000 AMP is equipped with a 3,700 mAh rechargeable battery to provide
9 hours of uninterrupted music playback.
– SP1000 AMP supports 9 hours of continuous unbalanced-output playback.
The black backing of the AMP represents shadows of the natural materials of the SP1000 and as the wavelengths of the sound splash in every direction, the reflected shadows express a divided silhouette.
The soft blue light surrounds the SP1000 volume wheel and accentuates the beautifully crafted crown pattern as the light shines upon it.
The precise angle of the wheel and the AMP surface, when combined together, has a functional space that does not interfere with the operation of the wheel and conveys the AMP status through the blue and red colours.
The SP1000 player locks to the amp, providing a simple and secure connection, giving you the feel of a single, united device.
Model: SP1000 AMP
Body Colour: Onyx Black / Stainless Steel / Copper
Body Material: Aluminium
Front Deco: Stainless Steel
Output Level: [Low Gain] Unbalanced 2.9 Vrms / Balanced 6.2 Vrms (Condition: No Load)
[High Gain] Unbalanced 6.2 Vrms / Balanced 10 Vrms (Condition: No Load)
Input: USB Type-C input
Outputs: Unbalanced Out (3.5mm) / Balanced Out (2.5mm, only 4-pole supported)
Dimensions: 2.98 ”(75.7 mm) [W] x 5.82 ”(148 mm) [H] x 0.35 ”(9 mm) [D]
Weight: 7.05 oz (200 g)
Frequency Response: [Low Gain] ±0.06 dB (Condition: 20 Hz – 20 kHz) Unbalanced / Balanced
[High Gain] ±0.06 dB (Condition: 20 Hz – 20 kHz) Unbalanced / Balanced
Signal to Noise Ratio: [Low Gain] 110 dB @ 1 kHz, Unbalanced / 111 dB @ 1 kHz, Balanced
[High Gain] 111 dB @ 1 kHz, Unbalanced / 111 dB @ 1 kHz, Balanced
Crosstalk: [Low Gain] 107 dB @ 1 kHz, Unbalanced / 131 dB @ 1 kHz, Balanced
[High Gain] 107 dB @ 1 kHz, Unbalanced / 131 dB @ 1 kHz, Balanced
