Ayon HA3 Headphone Amplifier (Ex-demo)

Ayon HA3 Headphone Amplifier (Ex-demo)

0.00 0.00

A great opportunity for a discount on a brilliant, single ended valve output headphone amplifier. In as new condition, with less that 100 hours use, a full manufacturers warranty and a 1 year warranty on the tubes.

sold out
Add To Cart

The HA-3 was developed for headphone lovers searching exclusively the very special music experience.

It impresses with it’s Single-Ended-Triode technology taken to its respective extremes by Ayon in all their products. Selected in-house AA45 Mesh super triodes, the perhaps most perfect and best sounding low-power triode for headphone amp design, are applied in combination with special super-permalloy wound output transformers.

For the Ayon HA-3, deliberately, all useless gimmicks have been omitted. The HA-3 is designed without compromise in its circuitry as well as in its power conditioning; therefore, a separate top-class power supply is included; it guarantees extraordinary voltage and current stability.

With its powerful, airy, and lively sound, paired with a superb spatiality with emotional reproduction the HA-3 drives every dynamic headphone to absolutely maximum tonal performance. From treble in brilliant resolution to absolutely authentic colourful mid-range and a deep solid bass. At the same time, it fascinates by its incredible ease, closeness and control at any kind of reproduction that is second to none


Tube Headphone amp

Ayon HA-3

  • Class of Operation: Pure Class A, SE-Triode
  • Tube Complement: 2 x AA45 Mesh, 2 x 12AU7
  • S/N Ratio: > 100dB (unweighted)
  • Input Impedance: 50 kΩ
  • Frequency Response at 32Ω: 15 Hz - 35kHz
  • Harmonic Distortion (at 150mV ): < 0.01%
  • Channel Separation L/R: > 89dB
  • Output Power at 32Ω: 500mV
  • Output Impedance - Headphone: 16Ω – 600Ω
  • Line Input: RCA phono sockets
  • Headphone output: ¼” Stereo Jack (6.35mm)
  • Power Consumption: ~ 65W
  • Dimensions Main Unit (WxDxH) cm: 22x30x20 cm
  • Dimension Power Supply (WxDxH) cm: 22x30x10 cm
  • Weight (Main): 8kg
  • Weight (Power Supply): 7kg
